Here are several ways to accomplish the flexibility of multitrack recording with different podcasting hardware and software.
Podcast: Play in new window | Download
Before you go down this path of learning how to record podcasts in multitrack, check out my previous episode about why and why not to record podcasts in multitrack.
Multitrack basics
To produce your podcast in multitrack, you three things:
- Separated audio channels (voices, sounds, etc.)
- Multitrack interface/recorder
- Multitrack editing software (also known as “digital audio workstation” or “DAW”)
1. Separated audio channels
Multitrack recording is pointless if all your audio is mixing together into the same track.
Every participant in your podcast should have their own microphone. This is not only necessary for separating the audio channels, but it's also necessary for clear listening. There are some exceptions, such as in-person newscaster-style interviews or high-end video with specialized equipment and techniques.
Podcasting with remote participants can make separating audio channels more complicated. For example, if you have multiple participants connected through the same method (such as Skype, Hangouts, telephone, and such), their voices are mixed into a single channel. You'll run into a similar complication if you use the same device for both remote participants and your soundtrack (music, segues, sound clips, etc.). I'll explain possible solutions further down.
Depending on your podcasting hardware and software workflow, you may have to make choices about how you separate audio channels. For example, you may be limited to only two channels, but you have three voices. In such a scenario, you must choose which channels to combine into the same track, such as in-studio cohosts on one track and remote participants on the other track.
2. Multitrack interface/recorder
When you have separated audio channels, you need a way to capture that audio without mixing everything together.
Most of the mixers within podcaster budgets may have multiple input channels, but only two output tracks. So even if you have a 6-track recorder, you'll be limited to the number of tracks your interface can support.
The inverse could also be a problem. You could have a multitrack mixer, but your recorder may be limited to only two tracks (stereo).
The ideal multitrack recorder will let you capture each audio channel into its own track, instead of combining channels into separate sides of a stereo track.
3. Multitrack editing software
Most audio- and video-editing software supports multitrack editing on PCs. But multitrack editing is not as common with mobile apps.
Workflow will vary with each app. Generally, you need the ability to edit or process one track without affecting the other, as well as the ability to edit or process multiple tracks.
For example, can you delete a cough from one track without deleting the words from another? Or can you delete something and have it shift all the tracks together and maintaining alignment?
Multitrack editing requires a little more knowledge of the tools, especially understanding things link synchronization, target tracks, cross-track edits, split-edits, and more. The most popular multitrack editors (including Audacity and Adobe Audition) already support these features.
With understanding these three basics, you can work with your particular tools or upgrade to the right tools to accomplish your needs.
How to separate tracks through PCs and mobile
If you host your podcast with remote participants, there are two ways to separate each voice (or soundtrack) into separate channels.
Record each participant independently at the source
This is usually called “double-ender” or “multi-ender.” It's the easiest way to get every participant on their own audio track and get the highest audio quality from each of them!
When you record the mix you receive, it can be susceptible to quality-limitations set by the software (maybe the app won't stream the audio any higher than 16 kbps) and also a victim of available bandwidth (due to Internet connectivity or the device's own processing power). The result could then be much lower quality than what was sent.
Thus, the core idea for multi-ender recording is to have each participant record the audio from their side. This means the recording comes directly from their equipment and is thus more likely immune to software and connectivity limitations (as long as they're using the right tools). Always test before you rely on this.
One way to accomplish this is by having each participant record their own side, such as through their own tools or software.This is a more complicated approach, and I would never recommend this for a guest who isn't already familiar with such tools. Always ensure the recording settings (especially the KHz rate and bit-depth) are the same for each participant and this will minimize the chance of audio that doesn't stay synchronized (also known as “drift”).
The other way to accomplish this is with specialized tools that handle the recording and synchronization. Such tools come and go, but here are the top three I recommend (as of October, 2016):
The multi-ender technique will give you multiple audio files, each with only one voice in them. If you don't use a tool that synchronizes these for you, I recommend you use something to capture a reference mix of everything. Then, have each participant take turns with a loud clap that will give you a spike for easily aligning your multiple tracks. (This same technique works for recording separate audio with video projects.)
Separate each participant into different different devices and channels
If you have more than one remote participant, the most effective way to record them in multitrack is to completely separate their audio. This gets complicated and expensive, because it means you need multiple audio interfaces and call “lines.”
For example, you could run multiple instances of Skype on a single PC and add multiple audio interfaces to that PC. This would allow each instance of Skype to send its audio to a specific audio interface, which then connects to different inputs and outputs on your mixer.
Alternatively, you could use completely separate devices for each participant. You can use separate PCs, smartphones, tablets, or even iPod Touches for each incoming participant. Again, this would require multiple inputs and outputs from your mixer.
What makes this even more complicated is that each input needs its own targetable output so that you can send that participant the mix of all the other tracks minus their own voice. That's why we call it “mix minus.” So if your mixer has only one auxiliary or effect output, then you're most likely limited to only a single mix minus.
You may be able to work around this if you have a fancy multitrack interface with your PC. But that may still require software to combine the separate tracks into virtual mix minuses for each participant.
See how complicated this can get? The more participants you want on their own tracks, the more expensive this gets. That's why many podcasters are turning to more modern, more intelligent multi-ender methods.
How to record multitrack with most devices (2-track stereo)
Nearly all audio mixers, interfaces, and recorders support stereo. Stereo can be considered a single track with both left and right tracks when you need audio-positioning effects (such as in music reviews, dramas, and other experiential effects). Otherwise, consider any stereo device to be a two-track device.
Capturing two separate tracks with a stereo device is probably the easiest method. Simply use the pan/balance controls to move one channel fully left and move the other channel fully right. This control is usually built into every channel on nearly all mixers.
This will sound a little weird while you're recording, because you'll hear yourself in one ear and the other audio (whether a person or your soundtrack) in another ear.
If your audio gear doesn't allow you to adjust the pan or balance of the audio, you could consider upgrading, or buying a simply splitter for your audio recording. But you must pay attention to what the splitter can actually do. Most “splitters” you see are really only cloning the same audio into two separate destinations instead of splitting one channel from the other.
When you use “stereo” for multitrack recording, you'll end up with completely different audio in the left side from the right side. For the love of audio, please don't publish your episodes sounding that way! It's not only a horrible listening experience (even if you reduce the stereo separation), but it could be impossible for some people to listen when they can use only a single earbud or headphone.
Fixing this separation is really easy. You could mixdown to mono when you create your MP3. But most editing software (even Audacity) will have a way to split a stereo track into separate mono tracks. I have a tutorial showing how to do that inside Podcasters' Society.
I have two cautions with this workflow.
- VOIP/live-streaming software—Depending on the program and interface, you may be sending stereo-separated audio to your audience (such as with “Studio Mode” in Hangouts on Air). But if the program uses mono (such as Skype or “Voice Mode” in Hangouts on Air), it may select only the left channel. Thus, put your voice—or whatever is supposed to go back out to your participants or live audio—in the left channel.
- Headphone leak and mic placement—If you follow my frequent recommendations to avoid plosives by pivoting your microphone around your mouth 45º to the right or left (so that it points at your mouth from a slight side), this places your microphone closer to one particular ear. Thus, it's easier for the microphone to capture audio leaking from your headphones. Since I recommend putting your voice in the left channel (in accordance with my previous caution), I also recommend putting your microphone on that same side. That would keep other audio from leaking into your microphone and causing a slight echo. Alternatively, you can reverse the orientation of your headphones or earbuds so that your audio is still in the left channel, but you put your left earbud or headphone in your right ear.
How to record multitrack with a recorder
Perhaps, instead of an app or an interface, you have a multitrack recorder. For example, the Zoom H6 records up to six tracks.
You could use such a device in the place of a mixer, audio interface, and PC and connect multiple audio sources directly to it. That works fine for in-person multitrack. Because the H6 isn't a mixer, you won't be able to do mix-minus to easy account for remote participants.
However, you could allow one remote participant to hear your local voices through the device's built-in microphone but route their own voice into the recorder (where your headphones are also connected).
Another way to handle the multitrack with a recorder is to use a mixer that has multiple separate outputs. For example, the Behringer 1204 line offers two main outputs and two alternate outputs (other mixers may offer “subgroup” outputs). This gives up to four separate output channels.
If you're not doing mix minus with your mixer, you could even use your auxiliary and effects outputs as two separate outputs.
Then, you may need some cables and adapters in order to send these to the right inputs on your recorder.
How to record multitrack with a multitrack mixer or interface
If your budget allows, you may consider a high-end digital mixer or audio interface that connects via USB 2.0 (or higher), Firewire, or Thunderbolt. These usually send each channel as a separate track, and then you simply need to set your recording software to record all the tracks (and perhaps map them appropriately). Even Audacity can record as many tracks as the single device supports!
Some mixers, such as the Behringer UFX1204 will also function as recorders and save the separate audio tracks to an external hard drive.
Make sure you research the multitrack device carefully. Many of these will record all tracks “prefader,” which means that any muting or fader adjustments on the device won't be reflected in the recording. That's not a huge inconvenience, but it could affect your workflow since it means each mic is effectively always unmuted.
It's complicated and expensive; do you really need it?
As you can tell, multitrack recording can be very complicated and get really expensive. Thus, I think you should consider whether you truly need all the flexibility you get with multitrack recording. Listen to my previous episode to further explore why or why not to record in multitrack. Consider what else you could do with the time and money it would cost for an ideal multitrack setup.
If you truly need the flexibility of multitrack, and you have regular cohosts, consider simple tools like Cast, Ringr, or Zencastr; or consider teaching your cohosts how to record and send you their own audio.
Thank you for the podcast reviews!
Your reviews encourage me and they help other people find the podcast. If you appreciate the podcasting information I share, please write your own review on Apple Podcasts, Podchaser or Stitcher!
Announcements
- For my upcoming 300th episode, listen to my first episode and either share a lesson for it, or tell me what you would tell that podcaster to help him improve.
Need personalized podcasting help?
I no longer offer one-on-one consulting outside of Podcasters' Society, but request a consultant here and I'll connect you with someone I trust to help you launch or improve your podcast.
Ask your questions or share your feedback
- Comment on the shownotes
- Leave a voicemail at (903) 231-2221
- Email feedback@TheAudacitytoPodcast.com (audio files welcome)
Connect with me
- Subscribe to The Audacity to Podcast on Apple Podcasts or on Android.
- Join the Facebook Page and watch live podcasting Q&A on Mondays at 2pm (ET)
- Subscribe on YouTube for video reviews, Q&A, and more
- Follow @theDanielJLewis
Disclosure
This post may contain links to products or services with which I have an affiliate relationship and may receive compensation from your actions through such links. However, I don't let that corrupt my perspective and I don't recommend only affiliates.
Related Content
Daniel,
I have up to 8 microphones live at one time and a skype or hangout call. I would like to be able to record multitrack to reduce headaches when guests don’t use proper mic technique. you recommend Behringer UFX1204 but it does not have enough channels. so I looked at reviews and some people were saying go with Presonus StudioLive 16.0.2. that is quite a difference in price. Can you point me towards a mixer that can record multitrack with up to 9 inputs and mix minus capabilities.
Thanks for all your work on the show. It really continues to make a difference
Whew! That’s a lot of tracks!
Yes, you’re going to have to consider more expensive gear to record that many separate tracks. Look at the MixPre-10, the Behringer UFX1604 (though I think that still doesn’t have enough inputs), or some other high-end multitrack recorder or interface. But yes, it’s going to be really expensive!
Alternatively, you could consider combining some tracks. Like maybe 2 mics per channel, and then you need only a 4-channel device. Or, you could put the people you know have good mic technique combined on one channel, and everyone else on separate channels. Then, maybe you could use the Zoom H6 with the EXH-6 to give you six separate recording channels. (I also have a Zoom H6 for Podcasters course.)
I apologize for taking so unbelievably long to respond. Turns out that Disqus never notified me of this or several other comments.
Can you record multitrack on something like zencastr or Cast and simultaneously have a backup single track recorded offline with a Zoom H4 or something in case something fatal happens with the multitrack?
In most cases, yes! Most of those multirack VoIP tools (CleanFeed, Zencastr, SquadCast, Ringr, etc.) will record each participant on a separate track. To make your backup recording, you would just need to feed your microphones and the audio from your computer into the external recorder. You could even still do a stereo left/right split, or use the extra tracks on your recorder to still split your in-studio voices from your remote voices. That’s how I’ve done it with my Once Upon a Time podcast for years.
I apologize for taking so unbelievably long to respond. Turns out that Disqus never notified me of this or several other comments.
Daniel,
Any tips on recording with 3 tracks (2 hosts, 1 guest) via Skype/Adobe Audtion/PreSonus? I can’t get the audio for the second host mic to be heard via Skype.
Hi, Sarah! In your situation, I’m guessing Adobe Audition is properly recording all three tracks, but it’s only your Skype guest who doesn’t hear everything (thankfully not themselves back).
This is happening because the Presonus is a multitrack interface. It routes each audio channel into a separate track going into your computer. Generally, these tracks would be the same numbers as your channels on the device: channel 1 goes to track 1, channel 2 to track 2, and so on. Stereo is two-track audio: the left side is track 1, and the right side is track 2. Skype is thus either taking a mix of tracks 1 and 2, or it’s taking only track 1 as a mono track.
Thus, the Presonus is bringing in tracks 1, 2, and 3 (or maybe it’s different depending on how you have things connected), but Skype is only accepting track 1 and maybe track 2. Thus, whatever is on a track Skype isn’t accepting is thus not being heard by the person on Skype. That’s a good thing when you don’t want the Skype guest to hear themselves back, but it’s a bad thing when you need them to hear your sound effects or cohost.
Thus, the most universal solution here is to mix what you want your Skype guest to hear and send them that mix. You can do that with VoiceMeeter Banana for Windows, or Loopback for macOS. There’s a possibility Presonus already provides the tools to make that virtual mix for you, but you would have to ask their support team.
I hope that helps!
I apologize for taking so unbelievably long to respond. Turns out that Disqus never notified me of this or several other comments.
[…] is that you can connect multiple XLR microphones (as well as 1/4″ or 3.5 mm lines) to mix and record in multitrack—without a computer! Plus, these recorders can be powered via batteries or an AC power adapter, so […]
So, I mistakenly and ignorantly purchased a Mackie ProFX8v2. I didn’t realize (for some reason) that each channel needs it’s own built-in pre-amp to be able to record in multi-track. I’m trying to start a basic podcast, and I need to be able to have at least 4 separate microphones to get their own tracks, all in-studio. It’s never going to be less than 2 people, and never more than 4 people, all in studio. So… sadly we need the flexibility. We all have very different voices and need different effects and editing to make ourselves sound as best as we can. And we have bad habits of talking over one another (which we should work on anyways), but we just want a professional sounding podcast out of the gate. I know that’s a bit far reaching, but you know what they say about first impressions. Anyways, any advice would help. Thanks!
I highly recommend the RØDECaster Pro for needs such as yours. Here’s a little more information about it: https://theaudacitytopodcast.com/rcp
Thank you for this review. On my part, I use the AceThinker Music Recorder to capture podcast in multi-track since it can record to 16-bit/44.1kHz audio quality. It can record system sound and microphone at the same time. You can also use its free plan on both Windows and Mac.
